Newman 1.5-Inch Platinum-Cured Silicone Tri-Clamp Gasket

Part Number: 40RX-PX-1.5

Clear platinum-cured silicone gasket for sealing standard 1.5-inch sanitary Tri-Clamp connections. The gasket is intended for high-purity pharmaceutical, biotechnology, food, beverage and other hygienic processing systems. It is USP Class VI compliant and has a standard Type I Tri-Clamp profile.

  • Manufacturer: Newman Sanitary Gasket Company
  • Submitted Part Number: 40RX-PX-1.5
  • Alternate Part Number Formats: 40RXPX-150; 40RXPX0150
  • Product Type: Standard sanitary clamp gasket
  • Connection Type: Tri-Clamp, Type I
  • Nominal Size: 1.5 in
  • Material: Platinum-cured silicone
  • Color: Clear
  • USP Compliance: USP Class VI
  • Recommended Applications: Pharmaceutical, biotechnology, food, beverage and high-purity processing systems
  • Inside Diameter: Approximately 1.39 in (35.3 mm)
  • Outside Diameter: Approximately 2.00 in (50.5 mm)
  • Sealing-Bead Diameter: Approximately 1.71 in (43.5 mm)
  • Typical Silicone Temperature Range: Approximately −62 to 176 °C (−80 to 350 °F)
  • Short-Term Temperature Limit: Approximately 204 °C (400 °F)
  • Steam and Chemical Resistance: Moderate; suitability depends on media, temperature and exposure duration
  • Manufacturer/Distributor Package: 25 gaskets
