Newman AS568-122 Black EPDM O-Ring

Part Number: USP-122-2107

Black, peroxide-cured EPDM O-ring manufactured from Newman compound 2107 for high-purity pharmaceutical, food, beverage and sanitary-processing applications. The O-ring conforms to AS568 dash size 122 and is suitable for aqueous media, hot water, steam, mild acids, alkalis and deionized water. The material is FDA-compliant and USP Class VI tested.

  • Manufacturer: Newman Sanitary Gasket Company
  • Manufacturer Part Number: USP-122-2107
  • Product Type: Sanitary O-ring
  • Standard Size: AS568-122
  • Material: EPDM
  • Compound: Newman 2107
  • Cure System: Peroxide-cured
  • Color: Black
  • Hardness: 70 Shore A nominal
  • Inside Diameter: 1.112 in ± 0.010 in (28.24 mm ± 0.25 mm)
  • Cross Section: 0.103 in (2.62 mm)
  • Approximate Outside Diameter: 1.318 in (33.48 mm)
  • USP Compliance: USP Class VI
  • FDA Compliance: 21 CFR 177.2600 for repeated food-contact use
  • Recommended Media: Water, hot water, steam, deionized water, mild acids, alkalis, alcohols and oxygenated sanitizing solutions
  • General EPDM Temperature Range: Approximately −48 to 162 °C (−55 to 325 °F); actual limits depend on the application
  • Petroleum-Oil Compatibility: Poor; verify before use with oils or hydrocarbons
  • Batch Traceability: Available from Newman
  • Standard Selling Unit: Likely each; not independently confirmed for this exact SKU
