Applications
- Whole blood collections
- All types of apheresis collections
- Plasma collections
- Leukoreduction processes
- Component processing
System Specifications
| Catalog Number | 2600 |
| Dimensions （L X W X H) | 26.7 x 11.2 x 18 cm |
| Operating Weight | 9.6 lbs (4.4 kg) |
| Unit | Ea |
Electrical Specifications
| Certifications | cTUVus |
| Power Input | 115 VAC 60 Hz 6.3 Amps 230 VAC 3A 50 Hz 4 Amps 100 VAC 50 Hz 6.3 Amps |
| RF Power Output | 150 Watt minimum into matched 50Ω load, at initial power up |
| Radio Frequency Output | 40.68 ± .02MHz |
Performance Factors
| Sealing Time | Approximately 1 Seconds |
| Max Seal Rate | Max Seal Rate |
| Seal width | .087 inches (2.21 mm) |
| Tear Strength | 3.99 lbs (1.8kg) – varies by tubing |
| Tubing | PVC, Whole blood, Apheresis, Plasma |
Operating Conditions
| Temperature | 4 to 38° C |
| Humidity | Up to 70% Relative Humidity |
| Altitude tested up to | 6562 FT / 2000 M |
